Output tool summary

Top  Previous  Next

These output tools appears after specifying the selection area.



Save

Opens a dialog for saving the image to any directory. Specify color depth and JPG file compression on the Output tab of the Options dialog box.



Copy

Copies the image to the Windows clipboard for pasting to other applications, including email.

Technical note: depending on the format used by the target program, your selected output color depth may not be applied. You can customize whats placed on the clipboard on the Output tab of the Options dialog box.



Print

Prints the image normal size, unless it doesn't fit the paper - in which case the image is reduced to fit. Specify orientation and time stamping on the Output tab of the Options dialog box.  Note about print quality



Print Fit

Proportionally enlarges (or shrinks) images to fit one page. Tip: for wide images, check mark Landscape in the Print Setup dialog. If the printout isn't sized correctly, check if the printer has its own fit or scale settings. Use the printers features, or CaptureWiz, but not both.



Sticky Note

Stickies enable you to keep pictures or information on the desktop for reference. Stickies that are open when you exit CaptureWiz reappear next time.

To hide all sticky notes, on the capture bar click View / Hide Stickies. Click again to make them reappear. This function is also available on the taskbar notification icon context menu.



Email

Opens a new email and attaches a compressed image file. Email notes



Editor

Opens the image in your preferred image editor.

To switch editors, click the Editor tab of the Options dialog box. More info.



Multi

Capture multiple areas without starting over. View the captured images in the viewer.



View

Opens the captured image in the viewer. From there, edit the image and choose multiple outputs.



Later

Saves the image to a temporary folder. View it later in the viewer.





Copy File Path

Copies the images file path to the clipboard. Handy for inserting captures into email.



To FAX a captured image:

1  Click Print.

2  In the Name field of the printer dialog, select a fax device, if available.
